1. Working principle and advantages and disadvantages of external clamp type ultrasonic flowmeter

The external clamp type ultrasonic flowmeter achieves non-contact measurement of liquid flow rate through the principle of ultrasonic time difference. It calculates the flow velocity by using the time difference between forward and backward propagation in the fluid, and combines it with the pipe diameter to obtain the flow rate. Working principle: Ultrasonic time difference method: Install a sensor upstream and downstream of the fluid pipeline, and the speed of ultrasonic waves is different when propagating in the forward and reverse directions. When flowing downstream, the propagation speed of ultrasonic waves increases; When flowing backwards, the propagation speed slows down. By measuring the time difference between forward and backward propagation, combined with the relationship between fluid velocity and time difference, the fluid velocity can be calculated. Flow calculation: Given the inner diameter of the pipeline, the volumetric flow rate of the fluid can be obtained by multiplying the flow velocity by the cross-sectional area of the pipeline. Advantages of non-contact measurement: The sensor is installed on the outer wall of the pipeline, without damaging the pipeline structure or inserting it into the fluid, avoiding contamination and interference to the fluid, especially suitable for scenarios with high hygiene requirements (such as the food and pharmaceutical industries). No pressure loss: There are no moving parts obstructing fluid flow during the measurement process, which does not generate additional pressure loss and can reduce system energy consumption. It is suitable for pressure sensitive fluid

transportation scenarios. Wide applicability: It can measure non-conductive liquids (such as oils and organic solvents), which makes up for the limitation of electromagnetic flow meters that can only measure conductive liquids. Suitable for various industries, including water supply, heating, water conservancy, metallurgy, chemical industry, machinery, energy, etc. Easy to install and cost-effective: No need to stop production or cut pipes, directly install with external clamps, saving installation costs and time. The equipment cost is lower than that of some invasive flow meters, and maintenance is simple, with significant long-term economic benefits. Disadvantages: High requirements for fluid cleanliness: The propagation time method is based on the linear propagation of ultrasonic waves in the fluid. If the liquid contains a large number of bubbles, solid particles, or impurities, it will scatter or absorb ultrasonic signals, resulting in increased measurement errors or even inability to work. Therefore, it is only applicable for cleaning liquids and gases. Pipeline condition limitations: The pipeline material must be uniform and have good sound transmission performance (such as metal or plastic). If the inner wall of the pipeline is heavily scaled or corroded, it will affect the efficiency of ultrasonic propagation. There are certain requirements for the shape and size of the pipeline, such as the need for special calibration for pipes with irregular shapes or small diameters. Sensitive to environmental interference: External vibrations, drastic temperature changes, or electromagnetic interference may affect the stability of the sensor, and it is necessary to carefully inspect and avoid strong interference sources dur
