1. Analysis of several factors affecting accuracy by electromagnetic flowmeter manufacturers. The accuracy of electromagnetic flowmeters is affected by various factors. The following are the main reasons affecting their accuracy: the influence of pipe diameter changes on measurement results. Intelligent electromagnetic flowmeters usually use the principle of center flow rate measurement, and their calibration process is completed in a specially designed pipeline. If there are differences between the actual measurement environments pipe diameter, flow field distribution, or pipeline roughness and the calibration environment, it will lead to changes in flow velocity distribution, thereby causing measurement errors. For example, reducing or expanding the diameter of a pipeline may alter the laminar flow state of the fluid, rendering the correspondence between the central velocity and the actual average velocity invalid. The problem of underground positioning of instruments is that electromagnetic flow meters themselves lack depth positioning devices and rely on winch depth counters to measure the depth of entry. The accuracy of the counter is affected by mechanical structure, sensor sensitivity, and environmental interference (such as temperature and vibration). If the depth data error is too large, it will cause the measurement results to be misaligned with the actual position, making the flow profile analysis lose its practical reference value. Therefore, depth correction needs to be combined with auxiliary means such as pressure sensors or inertial navigation modules to improve positioning accuracy. Due to structural design limitations, it is difficult to achieve continuous measurement of the flow profile inside the pipe column using conventional electromagnetic flow meters, resulting in time or spatial breakpoints in data acquisition. This discontinuity can mask transient changes in flow (such as interlayer flow) and increase the difficulty of data interpretation. For example, in layered water injection testing, intermittent data may not accurately reflect the dynamic water absorption of each layer, and the deficiency needs to be compensated for through multiple measurements or model interpolation. The calibration problem of the instrument is that the calibration medium for electromagnetic flowmeters is usually clean water. If the actual injected medium is sewage dust filter, chemical agents, or fluids containing solid particles, changes in medium density, viscosity, and conductivity will interfere with the electromagnetic induction signal, resulting in measurement deviation. For example, high viscosity media may reduce flow rate response speed, while impurity containing media may alter electrode polarization characteristics. Therefore, it is necessary to adjust the calibration parameters according to the characteristics of the medium or adopt on-site dynamic calibration methods to ensure measurement accuracy. Application case supplement: In the layered testing of underground storage electromagnetic flowmeter in Henan Oilfield, by optimizing the calibration process (such as using actual injection medium calibration) and depth correction algorithm, the measurement error was successfully controlled within ± 3%, verifying its adaptability under complex working conditions. This case demonstrates that optimizing equipment parameters and operating standards for specific application scenarios can significantly improve the accuracy and rel
