Diagram of flowmeter installation requirements

『Diagram of flowmeter installation requirements』Related information(clamp on meter|electromagnetic meter|venturi meterrotameter|orifice meter|ultrasonic flow meter|mass flow meter|coriolis mass flow meter|coriolis flow meter|magnetic flow meter|magmeter flow meter|magflow flow meter|mag meter flow meter|electromagnetic flow meter|vortex flow meter|turbine flow meter|thermal mass flow meter|thermal flow meter|rotameter flow meter)

1. How to install ultrasonic flowmeter correctly

Installation requirements for ultrasonic flowmeter FV series ultrasonic flowmeter The following parameters need to be input during routine measurement: 1 Outer diameter of pipeline 2 Pipe wall thickness 3 Pipe 4 Lining material parameters (including lining thickness and lining sound velocity if there is a regret bending configuration) 5 Fluid type 6 Probe type (as the host can support multiple different probes) 7 The input steps for the above parameter conditions of the probe installation method generally follow the following setting steps: 1 Enter MENU 1 to enter window 11, enter the outer diameter of the tube, and then press the ENT key; 2. Type ▼/- to enter window 12, enter the pipe wall thickness, and then type the ENT key; 3. Type ▼/- to enter window 14 ENT, ▲/+or ▼/- select the pipe and type the ENT key; 4. Enter the ENT key in window 16 by typing ▼/-, ▲/+or ▼/- after selecting the lining material; 5. Enter the ENT key in window 20 by typing ▼/-, ▲/+or ▼/- to select the fluid type, and then press the ENT key; 6. Enter the ENT key in window 23 by typing ▼/-, ▲/+or ▼/- to select the probe type, and then type the ENT key; 7. Type ▼/- to enter window 24 ENT, ▲/+or ▼/- select the installation method and then type the ENT key; 8. Type ▼/- to enter window 25, and install the probe according to the displayed installation distance and the installation method selected in the previous step Enter MENU 0 1 to enter window 01 and display the measurement results. The installation of ultrasonic flow meters is the simplest and most convenient among all flow meters. Simply select a suitable measurement point, input the pipeline parameters at the measurement point into the f

Diagram of flowmeter installation requirements
low meter, and then fix the probe on the pipeline. In order to ensure measurement accuracy, when selecting measurement points, it is required to choose a part of the fluid flow field with uniform distribution. Generally, troublemakers should follow the following principles: 1 Choose a pipe section filled with fluid that is uniformly dense and easy to transmit ultrasonic waves, such as a vertical pipe section (where the fluid flows upwards) or a horizontal pipe section The installation distance should be selected as a uniform straight pipe section with no valves, elbows, or reducers within 10 times the diameter of the straight pipe upstream and 5 times the diameter of the straight pipe downstream. The installation point should be sufficiently far away from interference sources such as valves, pumps, high-voltage electricity, and frequency converters. 3. Avoid installing at the highest point of the pipeline system or on vertical pipelines with free outlets (where fluid flows downward) For open or semi full pipes, flow meters should be installed at U-shaped pipe sections. 5. Fully consider the scaling condition on the inner wall of the pipe and try to choose pipe sections without scaling for measurement. When it cannot be met, scaling should be considered as lining for better measurement accuracy.

2. How to install electromagnetic flowmeter: Electromagnetic flowmeter wiring diagram

3. Flowmeter installation requirements are summarized as follows

Flowmeter installation requirements are summarized as follows:

1. Basic installation requirements: Flow direction should be consistent: in horizontal pipelines, vortex generators should be installed vertically.. In vertical pipelines, flow meters re
