Diesel Flow Meter for Generator and Boiler Feed Supply Volumetric Monitoring

Quick Answer: For diesel fuel supply to a generator set, use an oval gear positive displacement flow meter with pulse output and a local display. For boiler feed water, use an electromagnetic flow meter with 4-20 mA HART output and a PTFE liner. Silver Instruments supplies both meter types with calibration reports and factory pricing.

Because diesel is not conductive, an electromagnetic flow meter will not work on a generator supply line. The practical choice is an oval gear flow meter. It handles clean diesel from 0.5 L/h up to 1000 L/h depending on pipe size. Most generator fuel skids use DN15, DN20, or DN25 lines. The meter body can be 316L stainless steel or cast steel. Gears are often PPS or PTFE. Diesel viscosity is around 2 to 5 cP at normal skid temperature. That range works well with oval gear meters. Accuracy stays at ±0.5% of reading. Repeatability is ±0.1%. Pulse output goes directly to a PLC or a paperless recorder. We also add a 4-20 mA HART output when the control room needs a continuous signal.

Here is the thing. Many power plants in Southeast Asia and Africa still measure diesel by dipstick or by tank level. That method is not accurate. A small 500 kW generator can burn 120 to 180 litres per hour at high load. A one percent measurement error means a large volume over one month. One operator in Vietnam replaced dipstick checks with a DN20 oval gear meter last year. He found fuel consumption differences within the first week. The meter paid for itself quickly. Most engineers skip this part until a fuel audit shows a gap.

Boiler Feed Water Volume Measurement

In practice, boiler feed water is conductive in most plants. Conductivity is usually above 5 µS/cm. That is why an electromagnetic flow meter is a reliable choice. We recommend a DN25 to DN80 electromagnetic flow meter with PTFE liner and 316L electrodes. The output can be 4-20 mA HART or RS485 Modbus. Typical accuracy is ±0.5% of reading. Maximum fluid temperature is 120 °C. Pressure rating is PN40 for most sizes. This meter works well for feed water lines because there are no moving parts. No moving parts means low maintenance and stable readings over time.

If you need mass flow in kg/h for a boiler heat balance, add a PT100 temperature sensor and a flow computer. We can also quote a Coriolis mass flow meter when the budget allows. For welded pipes where the process cannot stop, a clamp-on ultrasonic flow meter is an option. It measures volume from outside the pipe. Accuracy is lower than an inline electromagnetic meter, but installation is faster. We have supplied clamp-on meters to desalination plants in the Middle East and food processors in Indonesia.

Why Diesel and Boiler Water Monitoring Are Linked

In a generator project, diesel volume tells you how much fuel

Diesel Flow Meter for Generator: Boiler Feed Supply Volumetric Monitoring

enters the engine. Boiler feed water volume tells you how much water is supplied to the steam loop. Comparing both volumes against steam output gives operators a fuel to water balance. That balance catches fuel theft, pump wear, leaking valves, and scaling issues. A 2 MW diesel generator can consume roughly 400 to 600 litres of diesel per hour depending on load. If the flow meter drifts, the plant report starts to show false efficiency numbers. Volumetric monitoring is not only about paperwork. It is about knowing the true cost per kilowatt hour and per tonne of steam.

Recommended Meter Setup

For generator diesel lines, specify an oval gear flow meter. Use DN15 for flows from 2 to 100 litres per hour. Use DN20 for 10 to 400 litres per hour. Use DN25 for 30 to 800 litres per hour. Ask for a pulse output, a 4-20 mA HART output, and a local LCD. Maximum pressure is 40 bar. Maximum temperature for diesel service is 80 °C. This model fits standard fuel skids and day tanks.

For boiler feed water, specify an electromagnetic flow meter. Use DN25 for flows from 0.5 to 10 cubic metres per hour. Use DN50 for 2 to 40 cubic metres per hour. Use DN80 for 5 to 100 cubic metres per hour. The liner should be PTFE or PFA. Electrodes should be 316L stainless steel. Add RS485 Modbus if the plant uses a DCS or a paperless recorder. Most customers choose IP67 protection for pump rooms. Choose IP68 if the meter may be flooded.

What to Send for a Quote

Send us your pipe size (DN), fluid type, flow range, pressure (bar), temperature (°C), and output signal. Also tell us if the diesel meter will be installed in an ATEX Zone 1 area. That changes the certification and the terminal box. Our engineers reply within 24 hours with a model selection and a USD price. Contact Silver Automation Instruments by phone at +86-25-68650347. WhatsApp is +86-25-52155837. WeChat is +86 15365082610. You can also visit flow-meter.com.au for product data sheets.

FAQ

Can an electromagnetic flow meter measure diesel fuel?
No. Diesel is not conductive enough. Use an oval gear flow meter or a turbine flow meter on diesel lines.

What is the best meter for boiler feed water volume?
An electromagnetic flow meter is the standard choice. It works well when conductivity is above 5 µS/cm.

Can one display read both diesel and water meters?
Yes. Both meters can send 4-20 mA HART or Modbus signals. A paperless recorder or PLC can totalise both values on one screen.

What accuracy should I expect on diesel generator fuel?
An oval gear meter gives ±0.5% of reading and repeatability of ±0.1%.

Do you supply ATEX Zone 1 diesel flow meters?
Yes. We can supply oval gear flow meters with ATEX Zone 1 certification for hazardous area fuel skids and generator rooms.
