1. Model Description of DTSD1352-C Three phase Rail type Multifunctional Energy Meter

Model Description of DTSD1352-C Three phase Rail type Multifunctional Energy Meter: DTSD1352-C is a three-phase rail type multifunctional energy meter, and its model naming follows certain rules. The following is a detailed explanation of each part of the model: DTSD: D: stands for Electric Energy Meter. T: Represents three phases. S: Represents multifunctionality, meaning that the energy meter has multiple measurement and metering functions. D: Once again referring to Electric Energy, the second D here is usually used to distinguish between different types of electric energy meters, such as DDS for single-phase electronic energy meters, DTS for three-phase four wire active electronic energy meters, etc. However, in DTSD, the second D is more often used as part of the model, emphasizing its versatility. 1352: These numbers are the design serial number or model code of the product, used to distinguish between different series or products with different functions. For DTSD1352, it represents a specific product line and configuration. -C: -: The suffix part representing the model, used to further subdivide the products functions or configurations. C: In this context, C may represent a specific configuration or function, such as communication interface, measurement accuracy, installation method, etc. The specific meaning may vary by manufacturer, but is usually related to the products technical specifications or user needs. Based on the above explanation, DTSD1352-C three-phase rail type multifunctional energy meter is an intelligent instrument designed for power systems, industrial and mining enterprises, public facilities and o

ther places. It has the advantages of high precision, compact size, and easy installation, and integrates common power parameter measurement, energy metering, and assessment management functions. Here are some additional instructions for this model of energy meter: Display mode: LCD display, providing a clear reading interface. Measurement parameters: including U (voltage), I (current), P (active power), Q (reactive power), S (apparent power), PF (power factor), F (frequency) and other electrical parameters. Energy metering: Supports active energy metering (forward and reverse) and reactive energy metering (forward and reverse), as well as phase wise active energy metering for A, B, and C. Harmonic measurement: capable of measuring 2-31st harmonic voltage and current, which helps analyze the harmonic condition of the power system. Programming and Communication: Communication parameters and ratios can be programmed through 4 buttons, supporting infrared communication and two-way RS485 interface communication, as well as communication protocols such as Modbus and DL/T645. Pulse output: Provides functions such as active pulse output, reactive pulse output, and clock pulse output. In addition, the DTSD1352-C energy meter also provides various energy data statistics for the past 48 months, making it convenient for users to manage and assess their energy. Its guide rail installation method makes the installation process easier and faster, suitable for various installation environments. The following are the technical parameter images and external dimension images of this model of electric energy meter (due to the limitation of the markdown format, the images will be displayed in the form of links, but should be able to preview
